Best Valuelithium Ion Battery for Energy Storage
Product details of the lithium ion battery for energy storage
Product Introduction
The appearance design of AINEGY lithium ion battery for energy storage are in line with the industrial standards. Its reliable performance outperforms similar products in the industry. The product can bring great value to customers and has become a hot product in the market.
Prduct Advantage
● Safe and reliable
● 2 Channels of high-voltage MPPT
● IP65 waterproof
● Support RS485 and WiFi
● High Voltage lithium battery
● 3 -phase AC output
Product Parameters
| Model Name | AIN-12KH3-A1 |
| Output(AC) | Nominal power | 12000VA |
| Max. power | 13000VA | |
| Max. output current | 20A | |
| Norminal output voltage | 400Vac/ 380Vac | |
| Norminal frequency | 50/ 60Hz | |
| Grid type | L1/ L2/ L3/ N/ PE | |
| PV Input | Max. DC power | 15000W |
| MPPT voltage range | 200~850Vdc | |
| Max. DC voltage | 1000Vdc | |
| Max input current/ per string | 13A*2 | |
| MPPT channels | 2 | |
| Battery Input | Battery Type | LiFePO4 Battery |
| Battery voltage range | 140~700Vdc | |
| Max. charge/ discharge current | 25A/ 25A | |
| AC Output (Back-up) | Max. AC power | 12000VA |
| Norminal output voltage | 400Vac/ 380Vac | |
| Norminal frequency | 50/ 60Hz | |
| Efficiency | Max. conversion efficiency | 98.2% |
| European efficiency | 97.5% | |
| Max battery to AC efficiency | 97.4% | |
| MPPT efficiency | 99.9% | |
| Safety and Protection | DC reverse-polarity protection | Yes |
| DC breaker | Yes | |
| DC/ AC SPD | Yes | |
| General Parameters | Dimension (W*H*D)/ mm | 548*444*184mm |
| Weight/ (kg) | 27kg | |
| Operating temperature range | -20~60℃ | |
| Degree of protection | IP65 | |
| Cooling concept | Natural convertion | |
| Humidity | 5% to 95% Relative Humidity (Non-condensing) | |
| Communication | WiFi | |
| BMS communication | CAN/RS485 | |
| Meter communication | RS485 |
product details
System working principle diagram
