Good Selling Commercial Energy Storage Solutions
Product details of the commercial energy storage solutions
Quick Overview
The quality of AINEGY commercial energy storage solutions is wonderful. Mature and stable production process ensures commercial energy storage solutions has perfect product performance. It can also be developed according to customer's drawings or samples.
Product Introduction
The following is the section for presenting commercial energy storage solutions's details.
Prduct Advantage
● Long cycle life
● Automotive grade process
● High integration and small size
● Integrated multi-level fire protection system
● Integrated BMS/ PCS / EMS
● Support UPS, off-grid and on-grid modes
Product Parameters
| Model Name | AIN-215KWH-100KH3M-HP1 |
| Battery | |
| Battery Type | LiFePO4 Battery |
| Rated Energy | 215KWh |
| Rated Capacity | 280Ah |
| Nominal Voltage | 768V |
| Max. Charge Voltage | 876V |
| Cut-off Discharge Voltage | 600V |
| Max. Charge Current | 200A |
| Max. Discharge Current | 200A |
| Main Function | OVP/UVP/OTP/OCP/SCP/IDP/BL etc. |
| PV | |
| Max. PV Voltage | 1000Vdc |
| MPPT Voltage Range | 150~650Vdc |
| Max. PV Current | 100A+100A |
| MPPT String | 2 |
| Rated Power | 100KW |
| Rated Voltage | 400Vac/230Vac (L1/L2/L3/N/PE) |
| Rated Frequency | 50Hz/60Hz |
| Max. AC Current | 145A |
| Off-grid | |
| Rated Power | 100KW |
| Rated Voltage | 400Vac/230Vac (L1/L2/L3/N/PE) |
| Rated Frequency | 50Hz/60Hz |
| Max. AC Current | 145A |
| Parallel | 10 |
| General Parameter | |
| Communication | RS485/WiFi |
| Fire Protection | Aerosol and Perfluorohexanone |
| Cooling Mode | Air Conditioner |
| IP Grade | IP54 |
| Altitude | <2000m |
| Work Temperature | —10℃~55℃ |
| Size/mm | 1450*1100*2050 |
| Weight/kg | 2400 (about) |
product details
System working principle diagram
Q&A
Company Advantages
With years of evolvement, Shenzhen Ainegy Technology Co., Ltd. has been recognized as an expert in developing, designing, and manufacturing commercial energy storage solutions. Our products sell well. We have built a solid customer base and completed a large number of orders from customers around the world. Shenzhen Ainegy Technology Co., Ltd. is well prepared to deal with all difficulties and challenges. Please contact.
With years of experience in production, we guarantee our product quality so you can purchase them with confidence. Feel free to contact us!
