Lithium Battery Energy Storage for Home Use Factory
Product details of the lithium battery energy storage
Quick Detail
AINEGY lithium battery energy storage has a design that incorporates functionality and aesthetics. The testing of the product achieves product superiority. The lithium battery energy storage developed by AINEGY is widely used in various fields. This product sells well in the global market and is widely considered to be of promising market prospect.
Product Description
lithium battery energy storage is more competitive than other products in the same category, as shown in the following aspects.
Prduct Advantage
● 5kwh Wall-mount/Floor-mount
● Ultra slim design
● Compatible with 20+ inverters
● Automotive-grade security architecture BMS
● Support 15 in parallel
● Intelligence LCD can choose inverter
Product Parameters
| Model Name | AIN-WM51100A-A1 |
| Battery Style | 51.2V100Ah |
| Energy | 5.12KWh |
| Nominal Voltage | 51.2V |
| Rated Capacity | 100Ah |
| End-of-charge Voltage | 54.0V/58.0V |
| End-of-discharge Voltage | 39.0/42.0V |
| Standard Charge Current | 50A |
| Max. Charge Current | 100A |
| Standard Discharge Current | 100A |
| Max. Discharge Current | 100A |
| Max. Peak Current | 200A |
| Charge/ Discharge Interface | M8 Terminal |
| Communication Interface | RS485/ CAN |
| Shell Material/ Color | Metal/ (White + Black) |
| Size | 590*410*145mm |
| Weight | 43/45Kg |
| Work Temperature Range | Charge：0℃-50℃Discharge：-15℃-60℃ |
product details
System working principle diagram
Q&A
Company Introduction
Shenzhen Ainegy Technology Co., Ltd. is a modern company in the industry. The main business includes production, processing and sales of Power Wall,All in One Ess,Brick Type LiFePo4 Battery,Standing type LiFePo4 Battery,Cabinet Type LiFePo4 Battery,Charger&Inverter,12V/24V LiFePO4 Battery,Forklift LiFePO4 Battery,Household Energy Storage Power Battery,Lithium Battery,BMS,Inverter. AINEGY regards the development prospects with an innovative and advancing attitude, and provides more and better services for customers with perseverance and sincerity. Our products are of reliable quality, with great cost performance and you can purchase them with confidence. If you are in need, please contact us for business discussion.
