Lithium Ion Battery Manufacturer - - AINEGY
Product details of the lithium ion battery manufacturer
Product Overview
Assembly quality of lithium ion battery manufacturer has been highly improved. The product is accurately manufactured to the highest quality standard. Shenzhen Ainegy Technology Co., Ltd. has an excellent-sales service system.
Product Introduction
Compared with ordinary products, our lithium ion battery manufacturer has the specific differences as follows.
Prduct Advantage
● IP65 waterproof
● 2 channels HV PV MPPT controller
● Fast charge current 100A
● Support RS485 and WiFi
● On-grid, off-grid and UPS
● Max support 6 sets parallel
Product Parameters
| Model Name | AIN-5KH1-A1 |
| Battery | |
| Battery Voltage | 48VDC |
| Battery Voltage Range | 41.5~58.5VDC |
| Battery Type | Li-ion Battery / LiFePO4 Battery |
| Communication Interface | RS485/CAN |
| Output/ Input (AC) | |
| Rated Power | 5500VA |
| Surge Power | 11000VA |
| Waveform | Pure sine wave |
| Rated Grid Voltage | 230VAC |
| Frequency | 50Hz / 60Hz |
| PV Input (DC) | |
| Max PV Power | 7000W |
| Max PV Voltage | 500VDC |
| Starting Voltage | 150V |
| MPPT Range | 120~430VDC |
| MPPT Quantity | 2 |
| Max PV Current | 120A |
| Off-grid Output | |
| Max Output Power | 5000W |
| AC Input Voltage | 230VAC |
| Frequency | 50Hz / 60Hz |
| UPS Switching Time | < 20mS |
| Overload Capacity | 110% 30S/120% 10S/150% 80mS |
| Efficiency | |
| Max Efficiency | 98% |
| Max Discharge Efficiency | 95% |
| MPPT Efficiency | 98% |
| Physical | |
| Dimension(D*W*H/mm) | 350*230*580 |
| Net Weight (kg) | 23.5kg |
| Communication Interface | USB/RS485/WiFi |
| Protection Degree | IP65 |
| Installation method | Wall Mounted |
| Environment | |
| Humidity | 5% to 95% Relative Humidity (Non-condensing) |
| Operating Temperature | -10℃ ~ 50℃ |
| Storage Temperature | -15℃ ~ 60℃ |
product details
System working principle diagram
Q&A
Company Information
Shenzhen Ainegy Technology Co., Ltd. (AINEGY) is a modern enterprise integrating R&D, production, sales and service. We run a main business of Power Wall,All in One Ess,Brick Type LiFePo4 Battery,Standing type LiFePo4 Battery,Cabinet Type LiFePo4 Battery,Charger&Inverter,12V/24V LiFePO4 Battery,Forklift LiFePO4 Battery,Household Energy Storage Power Battery,Lithium Battery,BMS,Inverter. We have a perfect and mature service team. Based on this, we can provide you with excellent services to seek mutual benefit and create a better future! Our products are guaranteed to be quality. Customers with needs are welcomed to contact us for purchase.
