Lithium Ion Battery Storage From China
Prduct Advantage
● IP65 waterproof
● 2 channels HV PV MPPT controller
● Long cycle life
● Support RS485 and WiFi
● On-grid, off-grid and UPS
● Max support 6 sets parallel
Product Parameters
| Model Name | AIN-12KW/A1 |
| PV | Max PV Power | 15.6KW |
| Max PV Voltage | 500Vdc | |
| MPPT Voltage Range | 150~430Vdc | |
| Max PV Current | 26+26+26 | |
| MPPT channels | 2+2+2 | |
| AC Output | Rated Power | 12KW |
| Max Power | 13.2KW | |
| AC Voltage | 230Vac | |
| Max AC current | 57.4A | |
| Norminal frequency | 50Hz/60Hz | |
| Battery | Battery type | Li-ion battery |
| Battery voltage range | 40-60Vdc | |
| Max charge/discharge current | 220A/220A | |
| BMS communication | RS485/CAN | |
| General parameters | Max.efficiency | 97.5% |
| MPPT efficiency | 99% | |
| Communication | WiFi | |
| Size(mm) | 450*250*710mm | |
| Weight(Kg) | 36 | |
| Cooling method | -30~55℃ | |
| IP garde | IP65 |
product details
System working principle diagram
Q&A
Company Advantages
· AINEGY lithium ion battery storage is made by raw materials which meet the quality standards.
· The product is in compliance with some of the toughest quality standards across the world.
· Compared with other products, this product has a higher potential value.
Company Features
· Shenzhen Ainegy Technology Co., Ltd. has become the preferred choice in manufacturing high-quality lithium ion battery storage. We have years of rich experience in the industry.
· Having introduced experienced technicians, the quality of lithium ion battery storage can be guaranteed.
· We grant our employees the greatest possible freedom from the outset. At every level, we encourage their willingness to organize and to take responsibility for their work themselves. Call now!
Application of the Product
Our lithium ion battery storage has a wide range of applications.
With rich manufacturing experience and strong production strength, AINEGY is able to provide professional solutions according to customers' actual needs.
