Prduct Advantage
● PCS+ LiFePO4 Battery+ MPPT + Generator Port
● Integrated BMS/ PCS/ EMS
● Integrated fire protection and Air-conditioner
● Automotive grade process
Product Parameters
Model | 48KWh+30KW | 60KWh+30KW |
Battery | ||
Battery Type | LiFePO4 | |
Rated Energy | 48KWh | 60KWh |
PV | ||
Max. Power | 38KW | |
Max. PV Voltage | 850Vdc | |
MPPT Voltage Range | 200~800Vdc | |
Max. PV Current | 30A+30A | |
MPPT Channels | 2 | |
AC (On-grid) | ||
Rated Power | 30KW | |
AC Voltage | 400Vac/230Vac | |
Rated Frequency | 50Hz/60Hz | |
Max. AC Current | 50A | |
AC (Off-grid) | ||
Rated Power | 30KW | |
AC Voltage | 400Vac/230Vac | |
AC Frequency | 50Hz/60Hz | |
Max. AC Current | 50A | |
Switching Time | <20ms | |
Parallel Number | 3 | |
General Parameter | ||
Communication Type | RS485/WiFi | |
IP Grade | IP54 | |
Fire Protection System | Yes | |
OperatingTemperature | -10~55℃ | |
Humidity Range | 5%~95% | |
Altitude | < 2000m | |
Battery Cooling Method | FAN | |
PCS Cooling Method | Intelligent cooling | |
Dimensions(W*D*H) | 660*910*1940mm | 660*910*1940mm |
Weight | 750kg(about) | 850kg(about) |
product details
System working principle diagram
