Prduct Advantage
● Suport PV and grid charging
● 48V LiFePO4 Battery
● High reliability &high security
● Cost-effective
Product Parameters
Model | 43KWh+30KW | 48KWh+30KW | 57KWh+30KW | 64KWh+30KW |
Battery | ||||
Battery Type | LiFePO4 | |||
Rated Energy | 43KWh | 48KWh | 57KWh | 64KWh |
Nominal Voltage | 51.2V | |||
PV | ||||
Max. Power | 33KW | |||
Max. PV Voltage | 500Vdc | |||
MPPT Voltage Range | 90~450Vdc | |||
Max. PV Current | 22A/Channel | |||
MPPT Channels | 6 | |||
AC (On-grid) | ||||
Rated Power | 30KW | |||
AC Voltage | 400Vac/230Vac | |||
Rated Frequency | 50Hz/60Hz | |||
Max. AC Current | 45A | |||
AC (Off-grid) | ||||
Rated Power | 30KW | |||
AC Voltage | 400Vac/230Vac | |||
AC Frequency | 50Hz/60Hz | |||
Max. AC Current | 45A | |||
General Parameter | ||||
Communication Type | RS485/WiFi | |||
IP Grade | IP54 | |||
Fire Protection System | Yes | |||
OperatingTemperature | -10~55℃ | |||
Humidity Range | 5%~95% | |||
Altitude | < 2000m | |||
Battery Cooling Method | FAN | |||
PCS Cooling Method | Intelligent cooling | |||
Dimensions(W*D*H) | 670*900*1560mm | 670*900*1560mm | 670*900*1560mm | 670*900*1560mm |
Weight | 550kg(about) | 550kg(about) | 650kg(about) | 650kg((about)) |
product details
System working principle diagram
