Prduct Advantage
● PCS+ LiFePO4 Battery+ MPPT + Generator Port
● Integrated BMS/ PCS/ EMS
● Integrated fire protection and Air-conditioner
● Automotive grade process
Product Parameters
Model | 100KWh+50KW | 115KWh+50KW | 128KWh+60KW |
Battery | |||
Battery Type | LiFePO4 | ||
Rated Energy | 100KWh | 115KWh | 128KWh |
PV | |||
Max. Power | 75KW | ||
Max. PV Voltage | 850Vdc | ||
MPPT Voltage Range | 200~800Vdc | ||
Max. PV Current | 60A+60A | ||
MPPT Channels | 2 | ||
AC (On-grid) | |||
Rated Power | 50KW | 50KW | 60KW |
AC Voltage | 400Vac/230Vac | ||
Rated Frequency | 50Hz/60Hz | ||
Max. AC Current | 70A | 85A | |
AC (Off-grid) | |||
Rated Power | 50KW | ||
AC Voltage | 400Vac/230Vac | ||
AC Frequency | 50Hz/60Hz | ||
Max. AC Current | 70A | 90A | |
Switching Time | <10ms | ||
Parallel Number | 3 | ||
General Parameter | |||
Communication Type | RS485/WiFi | ||
IP Grade | IP54 | ||
Fire Protection System | Yes | ||
OperatingTemperature | -10~55℃ | ||
Humidity Range | 5%~95% | ||
Altitude | < 3000m | ||
Battery Cooling Method | Air-Conditioner | ||
PCS Cooling Method | Intelligent cooling | ||
Dimensions(W*D*H) | 1060*1035*1850mm | 1060*1035*1850mm | 1060*1035*1850mm |
Weight | 1200kg(about) | 1320kg(about) | 1350kg(about) |
product details
System working principle diagram
